WayPro Autolubrications

WayPro Automatic Lubrication Systems

WayPro offers a range of automatic lubrication systems designed to provide consistent and controlled lubricant delivery to single points, enhancing machinery lifespan and reducing maintenance costs. These systems are suitable for various industries, including manufacturing, automotive, and food production.

How Single Point Automatic Lubricators Work

The lubricant delivery is typically achieved through spring-loaded, gas-driven, or electrochemical mechanisms, ensuring a controlled flow rate.

More than half of all unexpected bearing malfunctions are related to lubrication. Automatic lubricant dispensers can prevent bearing malfunctions in 75% of cases

Benefits of Automatic Lubrication Systems

Automatic lubrication systems dispense small, precise amounts of lubricant at regular, short intervals. This approach offers several advantages over manual lubrication, especially for large plants or machines in hazardous areas, where manual lubrication can be dangerous, impractical, and expensive.

Reduces costs and downtime
Reduces impurities and contamination
Improves work safety
Enables monitoring and provides an overview
Prevents under and over-lubrication
Extending machine service life

Download Brochures

For more detailed information, you can download our brochures

EC WayPro is an electronically controlled single-point lubrication system that is driven by a chemical reaction. Its function is based on the proven technology of an electrochemical reaction that produces non-reactive nitrogen (N2) through the systematic use of an electrolyte. This type of pressure generation makes it more temperature-independent than many conventional gas-powered lubrication systems. It’s highlighted as a cost-effective, reliable, safe, and ecological product. It’s presented as an ideal choice for users wishing to switch from manual to automatic lubrication, as well as those already familiar with automatic lubrication systems. The dispenser excels through user-friendliness and a good cost-performance ratio.

Drive

Gas-driven via electronically controlled chemical reaction

Operating Pressure

Max. 5 bar (73 psi)

Lubricant Volume

60 ml, 120 ml, 240 ml

Operating Temperature

−20 to +55 Celcius

Distribution Period

1, 3, 6, 9 & 12 months (modifiable at any time)

Dimensions (H x Ø)

60 ml: 91x77 mm; 120 ml: 111x77 mm; 240 ml: 156x77 mm

Temperature Independence

More temperature-independent than many conventional gas-powered systems.

Refilling

Self-filling possible, special fillings possible.

Benefits

Reliable, eco-friendly, cost-effective

WayPro X is a precise electromechanical single-point lubrication system. It is a reliable and easy-to-operate lubricant dispenser. Its precise delivery system makes it suitable for automatic lubrication of roller and friction bearings, gear racks, open transmissions, or chains. It features a robust, very precise drive motor. The performance of WayPro X is monitored with a clearly visible LED, and the lubricant cartridge’s filling level is always visible through its transparent housing

Drive

Electromechanical

Operating Pressure

Max. 7.5 bar (109 psi)

Lubricant Volume

60 ml, 150 ml, 250 ml

Operating Temperature

−20 to +60 Celcius

Distribution Period

1-12 months (freely selectable)

Dimensions (H x Ø)

60 ml: 138x84 mm; 150 ml: 151x84 mm; 250 ml: 183x96 mm

Temperature Independence

Temperature-independent flow rate.

Refilling

Empty / standard filling / special filling.

Benefits

Precise, reliable delivery, visual warning of malfunction.
